| Category | Subcategory | Details |
| Image Sensor | Sensor | CMOS Sensor |
| Resolution | 800 x 640 | |
| Frame Rate | 30fps | |
| Lens | Focal Length | Fixed Focus |
| Angle of View | Horizontal: 44°, Vertical: 34° | |
| Light Source | Illumination | Red LED, Blue LED, White LED |
| Aiming Light | Laser Aiming | |
| Indicator Light | Decoding Indicator | |
| Barcode Support | 1D Barcodes | Codabar, Code 39, Code 32 Pharmaceutical (PARAF), Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, MSI, GS1 Data Bar Omnidirectional, GS1 Data Bar Limited, GS1 Data Bar Expanded, China Post (Hong Kong 2 of 5), Korea Post. |
| 2D Barcodes | Code block A, Code block F, PDF 417, MicroPDF 417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN. | |
| Minimum Precision | 4mil | |
| Reading Distance | Code 39 | Resolution: 4mil, Depth of Field: 0-50mm |
| Code 128 | Resolution: 5mil, Depth of Field: 0-75mm | |
| QR | Resolution: 13mil, Depth of Field: 20-160mm | |
| PDF417 | Resolution: 15mil, Depth of Field: 0-140mm | |
| DM | Resolution: 15mil, Depth of Field: 0-100mm | |
| Data Matrix | Resolution: 6.3mil, Depth of Field: 0-70mm | |
| Input/Output | USB Communication | Complies with USB Standard Protocol |
| Rated Values | Battery Capacity | 2000MAH |
| Battery Performance | Charging Time | 7-9 hours |
| Number of Working Cycles | 20,000 | |
| Transmission Distance | 80-100 meters in open field | |
| Environmental Resistance | Temperature | Operating: -20 to +50°C, Storage: -30 to +60°C |
| Humidity | Operating: 5% to 85% (No Condensation), Storage: 5% to 85% (No Condensation) | |
| Protection Rating | IP66 | |
| Environmental Lighting | Sunlight: 10000 Lux, Incandescent Light: 6000 Lux, Fluorescent Light: 2000 Lux | |
| Drop Resistance | Can withstand multiple drops from 1.2 meters onto concrete (with a 5° deflection allowed) | |
| Mechanical | Physical Dimensions | 163.06mm x 106.23 mm x 69.45 mm |
| Weight | 180.5g | |
| Housing Material | PC | |
| Certifications | Explosion-Proof Rating | Ex ib ⅡC T4 Gb; Ex ib ⅢC T130℃ Db |
| Wireless Protocols | 2.4G Base with / Wireless Bluetooth 4.0 Support Protocols 2.0, 3.0, 4.0 |
